American Freedom series

Exterior

• Siding: Allura Panel Fibercement Traditional Cedar 30YR
• Siding Underlayment: House Wrap
• Trim: 3.5" Allura Fibercement
• Fascia: 7.5" Allura Fibercement
• Soffit: HardiSoffit Cedarmill
• Roofing: Architectural Shingles
• Roofing Underlayment: Sythetic
• Windows: Vinyl Frame Low-E Dual Glazed
• Front Door: 36" Six-Panel
• Rear Door: 36" Six-Panel
• Exterior Floor Decking: Stained Wood- per print
• Hose Bib: Optional
• Dormer: Optional

Siding: Allura Panel Fibercement Traditional Cedar 30YR
Siding Underlayment: House Wrap
Trim: 3.5" Allura Fibercement
Fascia: 7.5" Allura Fibercement
Soffit: HardiSoffit Cedarmill
Roofing: Architectural Shingles
Roofing Underlayment: Sythetic
Windows: Vinyl Frame Low-E Dual Glazed
Front Door: 36" Six-Panel
Rear Door: 36" Six-Panel
Exterior Floor Decking: Stained Wood- per print
Hose Bib: Optional
Dormer: Optional

Construction

• Frame: I-Beam Chassis
• Axles & tires: Recycled
• Floor Joist: 2x6 16"OC -13'6" floor (2x8-19.2"o/c for 14'8")
• Floor Decking: 19/32 OSB Tongue & Groove
• Exterior Walls: 2x6 16" OC / 96" Height
• Interior Walls: 24" OC
• Roof Trusses: 24" OC
• Roof Pitch & Load: 4/12 13'6" Wide, 30# , High & Low Roof Vents
• Eaves & Overhangs: 6" Eaves, 12" End Overhangs
• Ceiling: Flat
• Insulation: R40-R21-R38 (Ceiling - Walls - Floor)
• Heating: EB-15F Electric Furnace*
• Duct System: Insulated Graduated Fiberglass
• Heat Registers: In Line
• Air Return: Over Door
• Cross Overs: N/A
• Ventilation: Baths & Whole Home
• Air & Vapor Barrier: Sill Seal with Spray Vapor Barrier
• Crawl Space: N/A
• Attic Access: N/A

Frame: I-Beam Chassis
Axles & tires: Recycled
Floor Joist: 2x6 16"OC -13'6" floor (2x8-19.2"o/c for 14'8")
Floor Decking: 19/32 OSB Tongue & Groove
Exterior Walls: 2x6 16" OC / 96" Height
Interior Walls: 24" OC
Roof Trusses: 24" OC
Roof Pitch & Load: 4/12 13'6" Wide, 30# , High & Low Roof Vents
Eaves & Overhangs: 6" Eaves, 12" End Overhangs
Ceiling: Flat
Insulation: R40-R21-R38 (Ceiling - Walls - Floor)
Heating: EB-15F Electric Furnace*
Duct System: Insulated Graduated Fiberglass
Heat Registers: In Line
Air Return: Over Door
Cross Overs: N/A
Ventilation: Baths & Whole Home
Air & Vapor Barrier: Sill Seal with Spray Vapor Barrier
Crawl Space: N/A
Attic Access: N/A

Interior

• Drywall Finish: Textured & Painted Prism White
• Drywall Corners: Square Including Windows w/Wood Sill
• Marriage Line Close-Up: N/A
• Cabinets: Durabuilt with Adjustable Shelves
• Cabinet Doors: Picture Frame Alkorcell
• Cabinet Pulls: Satin Silver Knobs
• Countertops: Wilsonart Laminate
• Counter Edge: Wilsonart Laminate
• Backsplash: Stacked Ceramic Tile
• Interior Doors: White Raised Panel
• Interior Door Hardware: Silver Lever Handles
• Door Trim: 2 1/4" White Square Door Casing
• Baseboards: 2 1/4" Square Baseboard Vinyl Areas Only
• Ceiling Cove: N/A
• Closet Shelving: Wood With Dowel Rod
• Window Coverings: Plant Built Valances
• Blinds: Metal Miniblinds Throughout
• Carpet: Edgewater
• Pad: 7#, 7/16" Thick Rebond Carpet Pad
• Vinyl Flooring: Kitchen, DR, LR, Utility, & Baths
• Tile Flooring: Optional
• Laminate Flooring: Optional
• Accent Paint: Optional

Drywall Finish: Textured & Painted Prism White
Drywall Corners: Square Including Windows w/Wood Sill
Marriage Line Close-Up: N/A
Cabinets: Durabuilt with Adjustable Shelves
Cabinet Doors: Picture Frame Alkorcell
Cabinet Pulls: Satin Silver Knobs
Countertops: Wilsonart Laminate
Counter Edge: Wilsonart Laminate
Backsplash: Stacked Ceramic Tile
Interior Doors: White Raised Panel
Interior Door Hardware: Silver Lever Handles
Door Trim: 2 1/4" White Square Door Casing
Baseboards: 2 1/4" Square Baseboard Vinyl Areas Only
Ceiling Cove: N/A
Closet Shelving: Wood With Dowel Rod
Window Coverings: Plant Built Valances
Blinds: Metal Miniblinds Throughout
Carpet: Edgewater
Pad: 7#, 7/16" Thick Rebond Carpet Pad
Vinyl Flooring: Kitchen, DR, LR, Utility, & Baths
Tile Flooring: Optional
Laminate Flooring: Optional
Accent Paint: Optional

Kitchen

• Kitchen Sink: 7" Deep Stainless Steel Double Bowl
• Kitchen Faucet: Nickel Single Lever
• Kitchen Sink Front: Fixed Drawer Front
• Shut Off Valves: All Fixtures & Whole Home
• Range: Black Freestanding Electric
• Range Ventilation: Black Broan Vertical Range Hood
• Refrigerator: Black 18cf Top & Bottom Frost Free
• Over Refrigerator: Shelf
• Water Heater: Rheem 40 Gal Electric
• Water Heater Access: Access Panel
• Utility Plumbing: Plumb for Washer Single Lever Gate Valves
• Special Plumbing: Plumb for Icemaker
• Gas Lines: N/A

Kitchen Sink: 7" Deep Stainless Steel Double Bowl
Kitchen Faucet: Nickel Single Lever
Kitchen Sink Front: Fixed Drawer Front
Shut Off Valves: All Fixtures & Whole Home
Range: Black Freestanding Electric
Range Ventilation: Black Broan Vertical Range Hood
Refrigerator: Black 18cf Top & Bottom Frost Free
Over Refrigerator: Shelf
Water Heater: Rheem 40 Gal Electric
Water Heater Access: Access Panel
Utility Plumbing: Plumb for Washer Single Lever Gate Valves
Special Plumbing: Plumb for Icemaker
Gas Lines: N/A

Mechanical

• Mainpanel: 200 Amp Electrical Service
• Switches: Rocker Type
• Light Bulbs: LED Bulbs Installed
• Entry Lights: White Wall Mount Jelly Jar
• Closet Lights (Walk-in Size): Recessed LED Can Light
• Wall Light: Optional
• Dining Room Lights: Recessed LED Can Light
• Morning Room Lights: Single Pendant light per plan
• Kitchen Area Lights: (4) Recessed LED Can Lights
• Kitchen Sink Light: Recessed LED Can Light
• Island or Bar Lighting: Optional
• Utility & Hall Lights: 4" LED Can Light
• Bathroom Light: Bathroom Strip Lights Metro
• Bedrooms Lights: Overhead Ceiling Light 2 Bulb Metro
• Fan (Wire): Optional
• TV Jack (Plate & Conduit): Optional
• Phone Jack (Plate & Conduit: Optional
• Freezer (Wire): Optional
• Dryer Hookup: Wire 220V For Dryer
• GFCI Recept: (1) Exterior per plan
• Safety: Smoke Detectors

Mainpanel: 200 Amp Electrical Service
Switches: Rocker Type
Light Bulbs: LED Bulbs Installed
Entry Lights: White Wall Mount Jelly Jar
Closet Lights (Walk-in Size): Recessed LED Can Light
Wall Light: Optional
Dining Room Lights: Recessed LED Can Light
Morning Room Lights: Single Pendant light per plan
Kitchen Area Lights: (4) Recessed LED Can Lights
Kitchen Sink Light: Recessed LED Can Light
Island or Bar Lighting: Optional
Utility & Hall Lights: 4" LED Can Light
Bathroom Light: Bathroom Strip Lights Metro
Bedrooms Lights: Overhead Ceiling Light 2 Bulb Metro
Fan (Wire): Optional
TV Jack (Plate & Conduit): Optional
Phone Jack (Plate & Conduit: Optional
Freezer (Wire): Optional
Dryer Hookup: Wire 220V For Dryer
GFCI Recept: (1) Exterior per plan
Safety: Smoke Detectors

Bathroom

• Master Bathroom
• Tub / Shower: 60" 1-piece Tub/Shower Combo
• Tub / Shower Faucet: Single Control Anti-Scald Diverter
• Tub: N/A
• Lavy: China Sink With Overflow
• Lavy Faucet: Single Lever Lavy Faucet
• Toilet: Elongated Bowl
• Mirror: Trimmed Above Sink
• Hardware: Brushed Nickel Towel Hook & Tissue Holder
• Secondary Bathroom
• Tub / Shower: 60" 1-piece Tub/Shower Combo
• Tub / Shower Faucet: Single Control Anti-Scald Diverter
• Lavy: China Sink With Overflow
• Lavy Faucet: Single Lever Lavy Faucet
• Toilet: Elongated Bowl
• Mirror: Trimmed Above Sink
• Hardware: Brushed Nickel Towel Hook & Tissue Holder

Master Bathroom
Tub / Shower: 60" 1-piece Tub/Shower Combo
Tub / Shower Faucet: Single Control Anti-Scald Diverter
Tub: N/A
Lavy: China Sink With Overflow
Lavy Faucet: Single Lever Lavy Faucet
Toilet: Elongated Bowl
Mirror: Trimmed Above Sink
Hardware: Brushed Nickel Towel Hook & Tissue Holder
Secondary Bathroom
Tub / Shower: 60" 1-piece Tub/Shower Combo
Tub / Shower Faucet: Single Control Anti-Scald Diverter
Lavy: China Sink With Overflow
Lavy Faucet: Single Lever Lavy Faucet
Toilet: Elongated Bowl
Mirror: Trimmed Above Sink
Hardware: Brushed Nickel Towel Hook & Tissue Holder
